DGSM011 Side Mount Cabinet Drawer Slide in Cold Rolled Steel
- Item Number: DGSM011
- Finishing: Cold Rolled Steel
- Optional Length: 10″ / 12″ / 14″ / 16″
- Width: 30 mm
- Thickness: 0.65 x 0.65 x 0.65 mm
- Loading Capacity: 35 KG / 400 mm (16″)
- Feature: Strong Carrying Capacity / Smooth
- Installation: Side Installation 11.5 ± 0.2 mm
- Type: Drawer Runner
- Color: Black
About This Product
Our side mount drawer slide is a versatile and reliable solution for all your drawer needs. This innovative slide comes with a three-fold track, allowing for full extension and convenient access to your goods. Whether you require a single extension with a two-fold track or the full extension design, the Drawer Slide is built to meet your specific requirements. With its integrated nylon rubber stopper, this slide ensures that your drawers close gently and quietly.
Highlights
- Three-fold track for full extension and convenient access
- Nylon Rubber Stopper for quiet and gentle drawer closure
- High-quality solid metal ball bearings for smooth operation
- Multiple ball options for customizable performance (2 – 5 balls)
- Made of high-quality cold-rolled steel for durability
- Galvanized or painted surface for enhanced texture and protection
- Balance hole position for improved load capacity
- Strong load-bearing capacity of up to 100 lbs
- Durable fall protection for heavy use
- Build with user-friendly design and easy installation process
| Size | 10″ | 12″ | 14″ | 16″ |
| Length NL/mm | 254 | 304 | 354 | 404 |
| Drawer Length DL | 250 | 300 | 350 | 400 |
| Minimum Cabinet Depth | 270 | 320 | 370 | 420 |
| Packing (set)/carton | 10 | 10 | 10 | 10 |
